Texas Instruments TLA2024IRUGT

Part Number:

TLA2024IRUGT

Manufacturer:

Texas Instruments

Ventron No:

6382006-TLA2024IRUGT

Description:

12-bit, 4-channel, delta-sigma ADC with voltage reference, oscillator, PGA and I2C

ECAD Model:

Datasheet:

tla2024

Payment:

Payment

Delivery:

Delivery

Quick Request Quote

Please send RFQ , We will respond immediately.

Part Number
Quantity
Company
E-mail
Phone
Comments
  • One Stop Service

    One Stop Service

  • Competitive Price

    Competitive Price

  • Source Traceability

    Source Traceability

  • Same Day Delivery

    Same Day Delivery

Part Pictures

  • TLA2024IRUGT Detail Images
  • TLA2024IRUGT Detail Images

Specifications

Texas Instruments TLA2024IRUGT technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments TLA2024IRUGT.

  • Resolution (Bps)
    12
  • Sample rate (max) (ksps)
    3.3
  • Number of input channels
    4
  • Interface type

    Interface Type refers to the physical and electrical characteristics of the connection between an electronic component and other devices or systems. It specifies the type of connector, pin configuration, voltage levels, signal protocols, and data transfer rates supported by the component. Common interface types include USB, HDMI, Ethernet, RS-232, and I2C. Understanding the Interface Type is crucial for ensuring compatibility and proper communication between components in electronic systems.

    I2C
  • Architecture

    Architecture refers to the internal design and organization of an electronic component. It encompasses the arrangement of functional blocks, their interconnections, and the overall data flow within the component. The architecture determines the component's performance characteristics, such as speed, power consumption, and functionality. It also influences the component's size, cost, and reliability.

    Delta-Sigma
  • Input type

    Input Type refers to the type of signal that an electronic component can accept as input.

    Differential
  • Multichannel configuration
    Multiplexed
  • Rating
    Catalog
  • Reference mode
    Internal
  • Input voltage range (max) (V)
    5.5
  • Input voltage range (min) (V)
    0
  • Features
    Oscillator
  • Operating temperature range (°C)
    -40 to 85
  • Power consumption (typ) (mW)
    0.3
  • Analog supply (min) (V)
    2
  • Analog supply (max) (V)
    5.5
  • Digital supply (min) (V)
    2
  • Digital supply (max) (V)
    5.5

Description

The TLA2021, TLA2022, and TLA2024 devices (TLA202x) areeasy-to-use, low-power, 12-bitdelta-sigma (ΔΣ) analog-to-digital converters (ADCs) targeted for any type of system-monitoringapplications (such as supply or battery voltage supervision, current sensing, or temperaturemeasurements). Offered in an ultra-small, leadless, 10-pin X2QFN package, theTLA2021 and TLA2022 are single-channel ADCs while theTLA2024 features a flexible input multiplexer (MUX) with two differential orfour single-ended input measurement options.

The TLA202x integrate a voltage reference and oscillator.Additionally, the TLA2022 and TLA2024 include a programmable gain amplifier (PGA) withselectable input ranges from ±256 mV to ±6.144 V, enabling both large- and small-signalmeasurements.

The TLA202x communicate via anI2C-compatible interface and operate in either continuous or single-shotconversion mode. The devices automatically power down after one conversion in single-shotconversion mode, significantly reducing power consumption during idle periods.

All of these features, along with a wide operating supply voltage range, make theTLA202x suitable for power- and space-constrained, system-monitoringapplications.

TLA2024IRUGT More Descriptions
12-bit, 4-channel, delta-sigma ADC with voltage reference, oscillator, PGA and I2C 10-X2QFN -40 to 85
10-XFQFN Exposed Pad TLA2024 ACTIVE (Last Updated: 5days ago) PGA Selectable Address analog digital converter 370mum 0.0033MHz 6Weeks 3.3V
Adc, Delta-Sigma, 12Bit, 3.3Ksps, X2Qfn; Resolution (Bits):12Bit; Sampling Rate:3.3Ksps; Input Channel Type:Differential, Single Ended; Data Interface:I2C; Supply Voltage Type:Single; Supply Voltage Min:2V; Supply Voltage Max:5.5V; Rohs Compliant: Yes |TEXAS INSTRUMENTS TLA2024IRUGT
