Mallory Sonalert Products Inc. SC250D

Name: SC250D
Brand: Mallory Sonalert Products Inc.
SKU: 1688-SC250D
Availability: InStock
Rating: 5 (1 reviews)

Part Number:: SC250D

Manufacturer:: Mallory Sonalert Products Inc.

Ventron No:: 1688-SC250D

Description:: AUDIO PIEZO IND 6-250V PNL MNT

ECAD Model:

Datasheet:: SC250D

Payment:

Delivery:

Part Pictures

Specifications

Mallory Sonalert Products Inc. SC250D technical specifications, attributes, parameters and parts with similar specifications to Mallory Sonalert Products Inc. SC250D.

Factory Lead Time
5 Weeks
Mount
Panel
Mounting Type
Panel Mount
Operating Temperature
-30°C~65°C
Packaging
Bulk
Published
2005
Series
SC
Size / Dimension
1.687Dia 42.85mm
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Number of Terminations
2
Termination
Screw Terminal, Quick Connect Tab - 0.250 (6.35mm)
Max Operating Temperature
65°C
Min Operating Temperature
-30°C
Color
Black
Technology
Piezo
Current Rating
16mA
Frequency
2kHz
Approval Agency
cUL
Housing Color
Black
Operating Supply Current
16mA
Operating Mode
Single Tone
Max Supply Current
16mA
Input Type
AC, DC
Current - Supply
5mA~16mA
Voltage Range
60V~250V
Self Resonant Frequency
1.9kHz
Port Location
Top
Sound Pressure Level (SPL)
60dB @ 60V, 61cm
Driver Circuitry
Indicator, Internally Driven
Diameter
42.85mm
Height
32.9mm
Height Seated (Max)
1.399 35.54mm
Length
34.8mm
RoHS Status
Non-RoHS Compliant

Description

SC250D Overview
This product is manufactured by Mallory Sonalert Products Inc. and belongs to the category of obsolete (EOL) components. The images we provide are for reference only, for detailed product information please see specification sheet SC250D or the datasheet in PDF format. As a professional electronic components distributor, Ventron has five million electronic components available. Additionally, we have over 500,000 electronic components in stock ready for immediate shipment. If you have requirements, you can send us a quotation form to get the price of SC250D. We attach great importance to our customers' purchasing experience and are willing to establish a long-term cooperative relationship with you. If you have any questions or requirements, please feel free to contact us.

SC250D More Descriptions

Alarm; 60 to 250; 60 dBA @ 2 ft. and 60 V AC/DC; Panel; 1900 Hz 300 Hz;
Audio Indicator Piezo 60VDC/60VAC 250VDC/250VAC 16mA 60dBA 1600Hz to 2200Hz Panel Mount Screw Bulk
Piezo Buzzers & Audio Indicators MED CONT 60-250V
Single Tone Signal 1900 Hz Continuous Tone
EXEMPT FOR MILITARY / NATIONAL SECURITY
Transducer, Piezo, 1.9Khz, 72Dba, 250V; Transducer Function:Alarm; Tones:Continuous; Supply Voltage Min:60V; Supply Voltage Max:250V; Operating Current Max:16Ma; Sound Level Spl:72Dba; Resonant Frequency:1.9Khz; Product Range:- Rohs Compliant: No |Mallory SC250D
