Texas Instruments REF3133AIDBZT

Name: REF3133AIDBZT
Brand: Texas Instruments
SKU: 3283385-REF3133AIDBZT
Availability: InStock
Rating: 5 (1 reviews)

Part Number:: REF3133AIDBZT

Manufacturer:: Texas Instruments

Ventron No:: 3283385-REF3133AIDBZT

Description:: 3.3-V, 20-ppm/°C max, 100-μA, 3-pin SOT-23 series voltage reference

ECAD Model:

Datasheet:: ref3133

Specifications

Texas Instruments REF3133AIDBZT technical specifications, attributes, parameters and parts with similar specifications to Texas Instruments REF3133AIDBZT.

Factory Lead Time
6 Weeks
Lifecycle Status
ACTIVE (Last Updated: 1 day ago)
Mounting Type
Surface Mount
Package / Case
TO-236-3, SC-59, SOT-23-3
Surface Mount
YES
Number of Pins
3
Weight
1.437803g
Operating Temperature
-40°C~125°C TA
Packaging
Tape & Reel (TR)
Tolerance
±0.2%
JESD-609 Code
e4
Pbfree Code
yes
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Number of Terminations
3
ECCN Code
EAR99
Temperature Coefficient
20ppm/°C
Terminal Finish
Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory
Voltage References
Technology
CMOS
Terminal Position
DUAL
Terminal Form
GULL WING
Peak Reflow Temperature (Cel)
260
Number of Functions
1
Supply Voltage
5V
Terminal Pitch
0.96mm
Base Part Number
REF3133
Pin Count
3
Number of Outputs
1
Output Voltage
3.3V
Output Type
Fixed
Max Output Current
10mA
Number of Channels
1
Trim/Adjustable Output
NO
Analog IC - Other Type
THREE TERMINAL VOLTAGE REFERENCE
Operating Supply Current
100μA
Voltage - Input
3.35V~5.5V
Max Supply Current
100μA
Quiescent Current
115μA
Max Output Voltage
3.3V
Min Input Voltage
3.35V
Max Input Voltage
5.5V
Reference Voltage
3.3V
Reference Type
Series
Min Output Voltage
3.293V
Temp Coef of Voltage-Max
20 ppm/°C
Noise - 0.1Hz to 10Hz
43μVp-p
Noise - 10Hz to 10kHz
63μVrms
Height
1.22mm
Length
2.92mm
Width
1.3mm
Thickness
1mm
Radiation Hardening
No
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
Lead Free
Lead Free

Description

REF3133AIDBZT Overview
Our product features a surface mount mounting type, making it easy to install and secure onto a surface. With a weight of 1.437803g, it is lightweight and convenient for various applications. It is also compliant with the JESD-609 Code e4, ensuring its quality and reliability. The terminal form is designed in a gull wing shape, providing a secure connection. With a pin count of 3, it offers a sufficient number of pins for connections. The maximum supply current of 100μA allows for efficient power usage. This product is a series reference type, providing accurate and consistent results. Its compact size of 2.92mm in length and 1.3mm in width makes it suitable for various electronic devices. Moreover, it is ROHS3 compliant, meeting the latest environmental standards.

REF3133AIDBZT Features
±0.2% Tolerance
THREE TERMINAL VOLTAGE REFERENCE Analog IC
Peak Reflow Temperature: 260
Channel Number: 1
Max Output Voltage: 5.5V
Reference Voltage: 3.3V

REF3133AIDBZT Applications
There are a lot of Texas Instruments
REF3133AIDBZT Voltage Reference applications.

Cellular phones, notebook computers, PDAs, GPSs, and DMMs
Computer workstations
Suitable for use with a wide range of video RAMDACs
Smart industrial transmitters
PCMCIA cards
Automotive
3 V/5 V, 8-bit to 12-bit data converters
Precision data acquisition systems
High resolution converters
Industrial process control systems

REF3133AIDBZT More Descriptions

3.3-V, 20-ppm/°C max, 100-µA, 3-pin SOT-23 series voltage reference 3-SOT-23 -40 to 125
V-Ref Precision 3.3V 10mA 3-Pin SOT-23 T/R
VOLT REF, SHUNT, 3.3V, SOT-23-3; Type de référence: Série - Fixe; Gamme de produit: -; Tension de référence: 3.3V; Exactitude initiale: 0.2%; Coefficient de température: ± 10ppm/°C; Type de boîtier CI référence de tension: SOT
Voltage Ref, Series, 3.3V, Sot-23-3; Voltage Reference Type:Series - Fixed; Product Range:Ref3133 Series; Reference Voltage:3.3V; Initial Accuracy:0.2%; Temperature Coefficient:± 10Ppm/°C; Voltage Reference Case Style:Sot-23 Rohs Compliant: Yes |TEXAS INSTRUMENTS REF3133AIDBZT
