Mallory Sonalert Products Inc. MCP320Q
- Part Number:
- MCP320Q
- Manufacturer:
- Mallory Sonalert Products Inc.
- Ventron No:
- 404-MCP320Q
- Description:
- AUDIO PIEZO INDICATOR 3-20V TH
- ECAD Model:
-
- Datasheet:
- MCP320 Series Performance Curves
Mallory Sonalert Products Inc. MCP320Q technical specifications, attributes, parameters and parts with similar specifications to Mallory Sonalert Products Inc. MCP320Q.
- Factory Lead Time21 Weeks
- MountFlush, Through Hole
- Mounting TypeThrough Hole
- Package / CaseRadial
- Weight10g
- Operating Temperature-20°C~90°C
- PackagingBulk
- Published2006
- SeriesMCP
- Size / Dimension0.945Dia 24.00mm
- Part StatusActive
- Moisture Sensitivity Level (MSL)Not Applicable
- Number of Terminations2
- TerminationPC Pins
- Max Operating Temperature90°C
- Min Operating Temperature-20°C
- ColorBlack
- Voltage - Rated12V
- Voltage - Rated DC12V
- TechnologyPiezo
- Current Rating20mA
- Frequency3.15kHz
- Operating Supply Current25mA
- Operating ModeSingle Tone
- Max Supply Current25mA
- Input TypeDC
- Current - Supply3mA~25mA
- Voltage Range3V~20V
- Self Resonant Frequency3.15kHz
- Port LocationTop
- Sound Pressure Level (SPL)55dB @ 3V, 61cm
- Driver CircuitryIndicator, Internally Driven
- Nominal Supply Voltage (DC)12V
- Diameter24mm
- Height17mm
- Height Seated (Max)0.689 17.50mm
- Length24mm
- Width24mm
- RoHS StatusROHS3 Compliant
- Lead FreeLead Free
- RatingsWashable
MCP320Q Overview
This product is manufactured by Mallory Sonalert Products Inc. and belongs to the category of Alarms, Buzzers, and Sirens. The images we provide are for reference only, for detailed product information please see specification sheet MCP320Q or the datasheet in PDF format. As a professional electronic components distributor, Ventron has five million electronic components available. Additionally, we have over 500,000 electronic components in stock ready for immediate shipment. If you have requirements, you can send us a quotation form to get the price of MCP320Q. We attach great importance to our customers' purchasing experience and are willing to establish a long-term cooperative relationship with you. If you have any questions or requirements, please feel free to contact us.
This product is manufactured by Mallory Sonalert Products Inc. and belongs to the category of Alarms, Buzzers, and Sirens. The images we provide are for reference only, for detailed product information please see specification sheet MCP320Q or the datasheet in PDF format. As a professional electronic components distributor, Ventron has five million electronic components available. Additionally, we have over 500,000 electronic components in stock ready for immediate shipment. If you have requirements, you can send us a quotation form to get the price of MCP320Q. We attach great importance to our customers' purchasing experience and are willing to establish a long-term cooperative relationship with you. If you have any questions or requirements, please feel free to contact us.
MCP320Q More Descriptions
Audio Indicator Piezo 3VDC 20VDC 25mA 12VDC 55dBA 2650Hz to 3650Hz Through Hole Pin Bulk
Piezo Buzzers & Audio Indicators CONSTANT, 3-20VDC 3KHZ, MED, 24X18MM
MCP Series 3-20V Operating Voltage PC Mounting Buzzer
Audio Warning Device, Alarm, Electro-Acoustic, Constant,12VDC Sup,25mA,74dB/min. | Mallory Sonalert MCP320Q
ALARM; CONTINUOUS TONE; 3-20 VDC; 80 DB; 3.1 KHZ; 24X17.5 MM; PC PINS
AUDIO PIEZO INDICATOR 3-20V TH
French Electronic Distributor since 1988
Audible Signal Devices 3-20V MINILERT
MCP320 MINILERT SEALD ROHS STK
Transducer, Piezo, 3.15Khz, 74Dba, 20Vdc; Transducer Function:Alarm; Tones:Continuous; Supply Voltage Min:3V; Supply Voltage Max:20V; Operating Current Max:20Ma; Sound Level Spl:74Db; Resonant Frequency:3.15Khz; Product Range:- Rohs Compliant: Yes |Mallory MCP320Q
Piezo Buzzers & Audio Indicators CONSTANT, 3-20VDC 3KHZ, MED, 24X18MM
MCP Series 3-20V Operating Voltage PC Mounting Buzzer
Audio Warning Device, Alarm, Electro-Acoustic, Constant,12VDC Sup,25mA,74dB/min. | Mallory Sonalert MCP320Q
ALARM; CONTINUOUS TONE; 3-20 VDC; 80 DB; 3.1 KHZ; 24X17.5 MM; PC PINS
AUDIO PIEZO INDICATOR 3-20V TH
French Electronic Distributor since 1988
Audible Signal Devices 3-20V MINILERT
MCP320 MINILERT SEALD ROHS STK
Transducer, Piezo, 3.15Khz, 74Dba, 20Vdc; Transducer Function:Alarm; Tones:Continuous; Supply Voltage Min:3V; Supply Voltage Max:20V; Operating Current Max:20Ma; Sound Level Spl:74Db; Resonant Frequency:3.15Khz; Product Range:- Rohs Compliant: Yes |Mallory MCP320Q
